High Strength Nimonic 90 Rod High Temperature Nickel ISO9001 Udimet 90 Nickel Based
| Place of Origin | CHINA |
|---|---|
| Brand Name | HUONA |
| Certification | ISO9001 |
| Model Number | Nimonic 90 |
| Minimum Order Quantity | 15 |
| Price | Bargain |
| Packaging Details | Spool Package With Carton Box, Coil Package With Polybag |
| Delivery Time | 5-21DAYS |
| Payment Terms | MoneyGram,Western Union,T/T,L/C |
| Supply Ability | 300 tons per month |
Contact me for free samples and coupons.
WhatsAPP:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Nimonic 90 | Density | 8.18g/cm³ |
|---|---|---|---|
| Coefficient Of Expansion | 12.7 μm/m °C (20 – 100°C) | Modulus Of Elasticity | 213 KN/mm² 227 / 240 KN/mm² |
| Material | Nickel Chromium | Melting Point | 1370°C |
| Modulus Of Rigidity | 82.5 KN/mm² | ||
| Highlight | High Strength nickel alloy rod,Nickel Based nickel alloy rod,Nickel Based High Temperature Alloy |
||
You can tick the products you need and communicate with us in the message board.
Product Description
Product Information
Nimonic 90 Rod High Temperature Nickel
Nimonic 90 Rod is developed by replacing 20% of Ni in Nimonic-80A with cobalt. The addition of cobalt increases the solid solubility temperature of γ′. It also increases the solubility of carbon in the matrix and therefore influences the characteristics of carbide precipitation. The carbide dissolution temperature is lowered to about 900°C. Cobalt is a γ′ stabilizer and therefore imparts better high temperature strength. Both MC type and M23C6 type carbides are present in this material. The physical metallurgy of Nimonic alloys is given in ref. and the hot ductility studies are in refs.
Nimonic 90 is also known as Superimphy 90, Pyromet 90, and Udimet 90.
Nimonic 90 Rod Chemical Composition
The chemical composition of Nimonic 90 rod is given in the following table.
| Element | Content (%) |
|---|---|
| Nickel, Ni | Bal |
| Chromium, Cr | 18-21 |
| Iron, Fe | ≤1.5 |
| Cobalt, Co | 15-21 |
| Titanium, Ti | 2-3 |
| Aluminum, Al | 1.0-2.0 |
| Manganese, Mn | ≤1 |
| Silicon | ≤1 |
| Others | Remainder |
-
Nimonic 90 Rod Physical Properties
The following table discusses the physical properties of Nimonic 90 Rod.
| Properties | Metric | Imperial |
|---|---|---|
| Density | 8.18 gm/cm3 | 0.296 lb/in3 |
-
Nimonic 90 Rod Mechanical Properties
The mechanical properties of Nimonic 90 Rod are tabulated below.
| Properties | ||||
|---|---|---|---|---|
| Condition | Approx. tensile strength | Approx. operating temperature depending on load^^ and environment | ||
| N/mm² | ksi | °C | °F | |
| Annealed | 800 – 1000 | 116 – 145 | – | – |
| Annealed + Aged | 1200 – 1400 | 174 – 203 | up to 550 | up to 1020 |
| Spring Temper | 1200 – 1500 | 175 – 218 | – | – |
| Spring Temper + Aged | 1500 – 1800 | 218 – 261 | up to 350 | up to 660 |
