Medical Grade Standard Size Type T Thermocouple Plug with Copper-Constantan Contacts for Patient Monitoring
| Place of Origin | China |
|---|---|
| Brand Name | HUONA |
| Certification | ISO 9001 |
| Model Number | Type T |
| Minimum Order Quantity | 100 Pieces |
| Price | Negotiable |
| Packaging Details | Carton/Wooden Case |
| Delivery Time | 3 working days for stock, 15-25 days for production |
| Payment Terms | T/T,L/C,PayPal,Western Union |
| Supply Ability | 50000 Pieces per Month |
Product Details
| Thermocouple Type | Type T (Copper-Constantan) | Connector Size | Standard (Large) |
|---|---|---|---|
| Conductor Material | Copper / Constantan | Contact Plating | Nickel Plated |
| Body Material | Phenolic / PBT | Color Code | ANSI Blue / IEC Brown-White |
| Operating Temperature | -60C To 150C | Termination | Screw Terminal |
| Application | Patient Temperature Monitoring | Standards | ANSI MC96.1 / IEC 60584-3 |
| Highlight | Medical Grade Thermocouple Plug,Copper-Constantan Type T Connector,Standard Size Medical Thermocouple |
||
Product Description
Standard Size Type T Thermocouple Plug - Medical Grade
This standard size (large) Type T thermocouple plug pairs copper and constantan contacts to deliver the low-temperature accuracy that medical temperature monitoring depends on. The robust large-format housing offers a confident grip and stable mating for bedside monitors, laboratory analysers and reusable temperature probes used throughout clinical facilities.
Key Features
- Copper-constantan (Type T) contacts for precise low-range measurement
- Standard large-size housing for a secure, low-insertion-force mating
- Polarity-protected contacts reduce mis-wiring during fast connection
- Colour-coded body for instant identification in busy clinical environments
- Rugged phenolic / PBT shell resists repeated handling and cleaning
- Interchangeable with widely used standard thermocouple panel sockets
Technical Specifications
| Thermocouple Type | Type T, Copper-Constantan |
| Connector Format | Standard Size (Large) |
| Conductor Material | Copper / Constantan |
| Contact Plating | Nickel Plated |
| Body Material | Phenolic / PBT |
| Colour Code | ANSI Blue / IEC Brown-White |
| Operating Temperature | -60°C to +150°C |
| Termination | Screw / Ceramic Terminal |
| Reference Standard | ANSI MC96.1 / IEC 60584-3 |
Typical Applications
- Patient temperature monitoring at bedside
- Laboratory and clinical research instruments
- Reusable temperature probes and extension assemblies
- Physical therapy and rehabilitation temperature control
Why Choose Our Type T Plug
- Contacts are drawn from matched copper-constantan strip for consistent e.m.f. output
- Each batch is electrically checked for polarity and continuity before packing
- Low contact resistance keeps signal drift to a minimum over long service life
- Available with custom colour code, logo and packing for OEM programmes
Packing & Ordering
Supplied in HUONA colour boxes with shock-proof foam inserts, then packed in export-grade corrugated cartons. Standard carton holds 100 pieces. Tell us your required connector size, colour code and quantity and we will confirm a quotation the same day.
