Inconel 718 Nickel Alloy Round Bar UNS N07718 Solution Annealed ASTM B637 AMS 5662 for Aerospace Engine Components
| Place of Origin | Shanghai, China |
|---|---|
| Brand Name | ECER |
| Certification | ISO 9001:2015, ASTM B637, AMS 5662, NACE MR0175 |
| Model Number | IN718-RB |
| Minimum Order Quantity | 100 Kilograms |
| Price | USD 35-65 / Kilogram |
| Packaging Details | Export-grade seaworthy wooden case with moisture-proof VCI wrapping, or customized packaging per customer requirements |
| Delivery Time | 7 working days for stock, 15-30 days for production |
| Payment Terms | T/T |
| Supply Ability | 50000 Kilograms per Month |
Product Details
| Material Grade | Inconel 718 (UNS N07718 / 2.4668) | Product Form | Round Bar / Rod |
|---|---|---|---|
| Diameter Range | Customization | Length | Custom Cut Available |
| Standard | ASTM B637, AMS 5662, AMS 5663, NACE MR0175 / ISO 15156 | Condition | Solution Annealed, Aged (Precipitation Hardened), Hot Rolled, Cold Drawn, Forged |
| Density | 8.19 G/cm³ | Melting Point | 1260-1336°C (2300-2437°F) |
| Tensile Strength | ≥ 1275 MPa (185 Ksi) At Room Temperature | Yield Strength (0.2% Offset) | ≥ 1034 MPa (150 Ksi) At Room Temperature |
| Elongation | ≥ 12% In 4D | Hardness | 331-400 HBW (Aged Condition) |
| Surface Finish | Black, Bright, Peeled, Polished, Machined | Application | Gas Turbine Blades, Aerospace Engine Shafts, Nuclear Reactor Components, Oil And Gas Downhole Tools |
| Highlight | AMS 5662 ASTM B637 Certified,Solution Annealed Aged Condition,Aerospace Turbine Engine Grade |
||
Product Description
Inconel 718 Nickel Alloy Round Bar – UNS N07718
ECER supplies premium Inconel 718 (UNS N07718 / W.Nr. 2.4668) nickel-chromium alloy round bars engineered for extreme high-temperature and corrosive environments. As a precipitation-hardenable nickel-based superalloy, Inconel 718 delivers exceptional tensile strength, creep resistance, and fatigue life up to 704°C (1300°F), making it the material of choice for critical aerospace and energy applications.
Key Features
- Superior High-Temperature Strength – Maintains mechanical integrity at elevated temperatures, resisting creep and stress rupture under sustained loads
- Excellent Corrosion Resistance – Outstanding resistance to pitting, crevice corrosion, and chloride stress-corrosion cracking in sour gas environments
- Precipitation Hardenable – Achieves maximum strength through solution annealing followed by aging heat treatment, with minimal distortion
- Weldability – Excellent resistance to post-weld strain-age cracking, ideal for complex fabricated assemblies
- Cryogenic Performance – Retains ductility and toughness at cryogenic temperatures down to -253°C (-423°F)
Available Conditions
| Condition | Description | Typical Hardness |
|---|---|---|
| Solution Annealed | Heated to 927-1010°C, air cooled or faster. Optimal for subsequent machining and forming. | 240-300 HBW |
| Aged (Precipitation Hardened) | Solution annealed + 718°C/8h furnace cool to 621°C + 621°C/8h air cool. Maximum strength condition per AMS 5662. | 331-400 HBW |
| Hot Rolled | Rolled above recrystallization temperature. Suitable for general structural applications. | As rolled |
| Cold Drawn | Drawn at room temperature for enhanced surface finish and dimensional tolerance (h9/h10). | Work hardened |
Chemical Composition (wt%)
| Element | Ni | Cr | Fe | Nb+Ta | Mo | Ti | Al | Co | C |
|---|---|---|---|---|---|---|---|---|---|
| Spec | 50.0-55.0 | 17.0-21.0 | Balance | 4.75-5.50 | 2.80-3.30 | 0.65-1.15 | 0.20-0.80 | ≤1.0 | ≤0.08 |
Mechanical Properties (Aged Condition, Room Temperature)
| Property | Minimum Value | Typical Value |
|---|---|---|
| Tensile Strength | 1275 MPa (185 ksi) | 1380 MPa (200 ksi) |
| Yield Strength (0.2% Offset) | 1034 MPa (150 ksi) | 1138 MPa (165 ksi) |
| Elongation in 4D | 12% | 18% |
| Reduction of Area | 15% | 25% |
| Hardness | 331 HBW | 370 HBW |
Typical Applications
- Aerospace: Gas turbine blades, discs, shafts, casings, fasteners, and combustion chambers
- Oil & Gas: Downhole tools, tubing hangers, valve bodies, wellhead components in sour service
- Nuclear: Reactor core components, control rod drive mechanisms, springs, and bolting
- Marine: Propeller shafts, pump shafts, and seawater-resistant fasteners
- Power Generation: Industrial gas turbine hot-section components, steam turbine bolting
Quality Assurance
Every shipment includes a 3.1 Material Test Certificate (per EN 10204) with chemical analysis, mechanical test results, and dimensional inspection data. Ultrasonic testing (per AMS 2630), eddy current, and liquid penetrant inspection available upon request. Our Inconel 718 round bars are fully traceable from melt source to final delivery.
Packaging & Delivery
- Each bar individually wrapped with VCI (Volatile Corrosion Inhibitor) paper
- Packed in export-grade seaworthy wooden cases with moisture-proof lining
- Clear marking: material grade, heat number, size, weight, and standard on each piece
- Standard delivery: 7 working days for stock inventory, 15-30 days for mill production orders
Contact ECER today for a competitive quote on Inconel 718 round bars. Custom sizes, cut-to-length service, and testing certifications available to meet your project specifications.
