Non Magnetic 479.2 MPA Inconel 625 Nickel Chromium Iron Alloy Durable
| Place of Origin | CHINA |
|---|---|
| Brand Name | HUONA |
| Certification | ISO9001 |
| Model Number | Inconel 625 |
| Minimum Order Quantity | 5 |
| Price | Bargain |
| Packaging Details | Spool package with Carton box, Coil package with polybag |
| Delivery Time | 7-50 Days |
| Payment Terms | T/T,L/C,Western Union,MoneyGram |
| Supply Ability | 500 Tons Per Month |
Contact me for free samples and coupons.
WhatsAPP:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Ni Co Mn | Nickel(Min) | 58% |
|---|---|---|---|
| Thermal Conductivity | 9.8 W/m*℃ | Curie Point | -319℉ (-195℃) |
| Density | 8.44 G/cm3 | Yield Strength | 479.2-528.8 MPA |
| Condition | Hard / Soft | Sureface | Bright,Oxided |
| Delivery Time | 7-50 Days | Tensile Strength | 1276-1034 MPA |
| Melting Point | 1350℃ | Elongation | 34-54% |
| Highlight | Non Magnetic Inconel 625 Wire,Non Magnetic Nickel Chromium Alloy Wire,Durable Inconel 625 Wire |
||
You can tick the products you need and communicate with us in the message board.
Product Description
Non Magnetic 479.2 MPA Inconel 625 Nickel Chromium Iron Alloy
- Inconel Series
The Nickel Inconel 625 is a non-magnetic nickel-chromium superalloy that features superb corrosion resistance as expected by the presence of the aforementioned transition metals. Moreover, it is very strong and is characterized by the wide range of its fabrication possibilities.
The safe operating temperature range of Nickel Inconel 625 spans from -238℉ (-150℃) to up to 1800℉ (982℃), so it can be used in a wide spectrum of applications that require exceptional corrosion resistance characteristics.
Variable temperatures are not the only thing that the Inconel 625 can withstand, as the same applies for variable pressures and very harsh environments that induce high rates of oxidation. In general, it finds application in sea-water applications, the chemical processing industry, the nuclear energy field, and also the aerospace sector.
As it is evident from the latter especially, the Inconel 625 is also very resistant to cracking, rupture and creeping damage, featuring high tensile strength and extraordinary corrosion versatility.
-
Chemical Properties of Inconel 625
| Nickel | Chromium | Molybdenum | Iron | Niobium and Tantalum | Cobalt | Manganese | Silicon |
| 58% | 20%-23% | 8%-10% | 5% | 3.15%-4.15% | 1% | 0.5% | 0.5% |
Chemical Composition
|
Grade |
Ni% |
Cr% |
Mo% |
Nb+Ta% |
Fe% |
Al% |
Ti% |
C% |
Mn% |
Si% |
Cu% |
P% |
S% |
|
Inconel 625 |
Min 58 |
20-23 |
8-10 |
3.15-4.15 |
Max 5 |
Max 0.4 |
Max 0.4 |
Max 0.1 |
Max 0.5 |
Max 0.5 |
Max 0.5 |
Max 0.015 |
Max 0.015 |
Specifications
|
Grade |
UNS |
Werkstoff Nr. |
|
Inconel 625 |
N06625 |
2.4856 |
Physical Properties
|
Grade |
Density |
Melting Point |
|
Inconel 625 |
8.4 g/cm3 |
1290°C-1350 °C |
Mechanical Properties
|
Condition |
Tensile Strength |
Yield Strength σp0.2/MPa |
Elongation |
Brinell Hardness |
|
Annealing Treatment(Grade 1) |
850 Mpa |
450 Mpa |
30% |
≤220 |
|
Solution Treatment (Grade 2) |
700 Mpa |
300 Mpa |
30% |
≤200 |
Inconel 625 Grade 2 is recommended for components that require optimum resistance to creep or rupture. Fine-grained (annealed) material may be advantageous at temperatures up to 1500°F with respect to fatigue strength, hardness, and tensile and yield strength.
Our Production Standard
|
Standard |
Bar |
Forging |
Pipe |
Sheet/Strip |
Fittings |
|
ASTM |
ASTM B446 |
ASTM B564 |
ASTM B444/B704/B705 |
ASTM B443 |
ASTM B366 |
- Application
Some typical applications are:
- The core of mooring cables
- Submarine propeller blades
- Submarine propulsion unit caging
- Navy boat exhaust ducts
- Undersea communication cables sheathing
- Other submerged systems or instruments
- Aircraft ducts and exhausts
- Thrust-reversers
- Engine compartment housing
- Fuel and hydraulics tubing
- Turbine seals
- Reactor core components
- Fuel control rod components
- General plant equipment
- Vessels
- Honeycomb heat exchangers
- Various types of industrial tubing
- Distillation columns
- Valves
- Super-heated potassium and sodium solar power stations tubing
