Silver Coated Copper Wire for Electronics High Conductivity Stable Signal Transmission
| Place of Origin | Shanghai |
|---|---|
| Brand Name | Huona |
| Certification | ISO9001,SGS |
| Model Number | Silver Plated Copper Wire |
| Minimum Order Quantity | 10--50KG |
| Price | Negotiable |
| Packaging Details | Cartons/Wooden case |
| Delivery Time | 5-21days |
| Payment Terms | L/C,T/T,Western Union,MoneyGram |
| Supply Ability | 500tons per month |
Contact me for free samples and coupons.
WhatsAPP:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Silver Plated Copper Wire | Base Copper Purity | ≥99.95% |
|---|---|---|---|
| Silver Plating Thickness 1um-10um(customizable) | 1μm-10μm(customizable) | Tensile Strength | 280-380 MPa |
| Elongation | ≥18% | Operating Temperature | 65°C To 150°C |
You can tick the products you need and communicate with us in the message board.
Product Description
Silver Coated Copper Wire for Electronics High Conductivity Stable Signal Transmission
Silver-plated copper wire combines copper's high conductivity with silver's superior electrical performance and corrosion resistance. The pure copper core provides a low-resistance base, while the silver plating enhances conductivity and protects against oxidation. It is widely used in high-frequency electronics, precision connectors, and aerospace wiring systems.
Key Features
- Ultra-high conductivity: Enables minimal signal loss in high-frequency applications
- Excellent corrosion resistance: Silver plating resists oxidation and chemical erosion
- High-temperature stability: Maintains performance in elevated temperature environments
- Good solderability: Facilitates reliable connections in precision assembly
- Low contact resistance: Ensures stable electrical signal transmission
Technical Specifications
| Attribute | Value |
|---|---|
| Base Copper Purity | ≥99.95% |
| Silver Plating Thickness | 1μm–10μm (customizable) |
| Wire Diameters | 0.2mm, 0.3mm, 0.5mm, 0.8mm, 1.0mm, 1.2mm (customizable) |
| Tensile Strength | 280–380 MPa |
| Elongation | ≥18% |
| Electrical Conductivity | ≥100% IACS |
| Operating Temperature | -65°C to 150°C |
Chemical Composition
| Component | Content (%) |
|---|---|
| Copper (Core) | ≥99.95 |
| Silver (Plating) | ≥99.9 |
| Trace Impurities | ≤0.05 (total) |
Product Specifications
| Item | Specification |
|---|---|
| Available Lengths | 50m, 100m, 300m, 500m, 1000m (customizable) |
| Packaging | Spooled on anti-static plastic spools; packed in sealed cartons |
| Surface Finish | Bright silver-plated (uniform coating) |
| Breakdown Voltage | ≥500V (for 0.5mm diameter wire) |
| OEM Support | Custom plating thickness, diameters, and labeling available |
Material Standards: Copper complies with ASTM B3 (electrolytic tough-pitch copper). Silver plating follows ASTM B700 (electrodeposited silver coatings). Electrical conductors meet IEC 60228 and MIL-STD-1580 standards.
We also supply other high-performance plated copper wires, including gold-plated copper wire and palladium-plated copper wire. Free samples and detailed technical datasheets are available upon request. Custom specifications can be tailored to meet specific high-precision application requirements.
All specifications are subject to customization based on application requirements.
