High Strength Nickel Alloy Incoloy 800 800H Pipe With Excellent Resistance ASTM

  • High Strength Nickel Alloy Incoloy 800 800H Pipe With Excellent Resistance ASTM
Place of Origin China
Brand Name HUONA
Certification ISO9001, RoHS
Model Number Incoloy 800h
Minimum Order Quantity 1KG
Price Need to negotiate
Packaging Details Carton, Wooden Case
Delivery Time Around a week
Payment Terms T/T
Supply Ability 2000Tons/ Year

Contact me for free samples and coupons.

WhatsAPP:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Incoloy 800 800H Pipe/Tube Product Grade Incoloy 800 800H
Product Shape Tube/pipe Material Nicr Iron
Alloy Nicr Iron Alloy Sample Support
Highlight

High Strength Nickel Silver Tubing

,

ASTM Nickel Silver Tubing

,

ASTM Nickel Alloy Pipe
Leave a Message
Product Description

Product Description



Basic Info.

Model NO.
Incoloy 800/800H
Delivery Time
7-15 days
Name
Inconel 800/800H Pipe
Surface
Bright
Criterion
ASTM
Diameter
Customized
Custom service
Support
Transport Package
Wooden Case
Specification
Customized
Trademark
HUONA
Origin
China
HS Code
7226999090
Production Capacity
2000 Tons/Year

Product Description

Nickel Alloy Incoloy 800 800H Pipe and Tube
General Description
Incoloy 800 /800H is a nickel-iron-chromium alloy with good strength and excellent resistance to oxidation and carburization in high-temperature atmospheres.
A high chromium content gives Incoloy 800 good resistance to oxidation. It also resists many aqueous media and is relatively free from stress-corrosion cracking. Incoloy 800 has excellent resistance to at concentrations up to approximately 70% and at temperatures up to the boiling point. It also has good resistance to organic acids, such as formic, acetic, and propionic. It resists a variety of oxidizing and nonoxidizing salts, but not halide salts.
Typical applications are heat treating equipment, petrochemical pyrolysis tubing and piping systems, sheathing for electrical heating elements, food processing equipment.
Chemical Composition

Grade Ni% Cr% Fe% C% Mn% S% Si% Cu% Al% Ti%
Incoloy 800 30.0-35.0 19.0-23.0 Min 39.5 Max 0.10 Max 1.50 Max 0.015 Max 1.0 Max 0.75 0.15-0.60 0.15-0.60

Grade Ni% Cr% Fe% C% Mn% Si% Cu% S% AL% Ti% Al+Ti%
Incoloy 800H 30.5-35.0 19.0-23.0 Bal. 0.05-0.10 Max 1.5 Max 1.0 Max 0.75 Max 0.015 0.15-0.60 0.15-0.60 0.30-1.20
Incoloy 800HT 30.0-35.0 19.0-23.0 Bal. 0.06-0.10 Max 1.5 Max 1.0 Max 0.75 Max 0.015 0.25-0.60 0.25-0.60 0.85-1.20

Specifications
Grade UNS Werkstoff Nr.
Incoloy 800 N08800 1.4876

Grade UNS Werkstoff Nr.
Incoloy 800H N08810 1.4958
Incoloy 800HT N08811 1.4959

Physical Properties
Grade Density Melting Point
Incoloy 800 8.0 g/cm3 1350°C-1400 °C

Grade Density Melting Point
Incoloy 800H/800HT 8.0 g/cm3 1370°C-1400 °C

Mechanical Properties
Grade Tensile Strength Yield Strength Elongation
Incoloy 800 520 N/mm² 205 N/mm² 30%

Alloy Tensile Strength Yield Strength Elongation
Incoloy 800H/800HT 450 N/mm² 170 N/mm² 35%

Welding of Incoloy 800
Any traditional welding procedures can be used to weld Incoloy 800 to similar alloys or other metals, such as gas tungsten arc welding(GTAW), plasma arc welding (PAW), metal inertia gas welding (MIG) and so on. Before welding, remove scale, grease, mark and imprint.
Recommend filler wire regarding welding Incoloy 800: ERNiCrMo-3


Nickel Alloy/Super Alloy UNS GB/T 14992 GB/T 15007 DIN JIS
Nickel200/Ni200 N02200         2.4060
Nickel201/Ni201 N02201         2.4061
Nickel270/Ni270 N02270
Monel400 N04400         2.4360
Monelk500 N05500         2.4375
Inconel600/Alloy600 N06600     NS3102 NS312 2.4816 NCF600
Inconel601/Alloy601 N06601     NS3103 NS313 2.4851
Inconel625/Alloy625 N06625     NS3306 NS336 2.4856 NCF625
Inconel690/Alloy690 N06690     NS3105 NS315 2.4642
Inconel718/Alloy718 N07718 GH4169 GH169     2.4668
Inconel725/Alloy725 N07725
Inconel738LC/Alloy738   K438 K38
Inconel X-750/AlloyX-750 N07750 GH4145 GH145     2.4669 NCF750B
Incoloy A286/Alloy286 S66286 GH2132 GH132     1.4980 SUH660
Incoloy800/Alloy800 N08800     NS1101 NS111 1.4876 NCF800
Incoloy800H N08810     NS1102 NS112 1.4876
Incoloy800HT N08811         1.4876
Incoloy825/Alloy825 N08825     NS1402 NS142 2.4858 NCF825
Incoloy925/Alloy925 N09925
Incoloy926/Alloy926 N08926         1.4529
Hastelloy B N10001     NS3201 NS321
Hastelloy B-2 N10665     NS3202 NS322 2.4617
Hastelloy C-4 N06455     NS3305 NS335 2.4610
Hastelloy C-22 N06022     NS3308 - 2.4602
Hastelloy C-276 N10276     NS3304 NS334 2.4819
Hastelloy C-2000 N06200     NS3405   2.4675
Hastelloy X/Alloy X N06002 GH3536 GH536     2.4665
Alloy 20/Alloy 20cb/Carpenter cb3 N08020     NS1403 NS143 2.4660
    GH4049 GH49     2.4636
    GH4033 GH33
    GH4043 GH43
    GH3030 GH30     2.4983
    GH1131 GH131
  F15 4J29       1.3912 EMAS-1001
    4J33
Invar36 K93600 4J36       1.3912
    3J21
    3J58
904L N08904         1.4539
AL6XN N08367
Alloy59 N06059         2.4605
Nictronic50 S20910
Nictronic60
